The Techtom Probe Sonicator is a laboratory ultrasonic processing system designed for efficient sample homogenization, cell disruption, emulsification and dispersion. Its probe-based ultrasonic technology delivers high-frequency energy directly into the sample, making it suitable for applications that require controlled and efficient sonication.

The instrument features a 4.3-inch TFT touchscreen display with a large LCD interface and time-setting functions. Its microprocessor control system is completely programmable, allowing users to set operating parameters according to their sample-processing requirements.

The system operates at a 20–25 kHz frequency with automatic tracking and includes an automatic fault alarm for convenient operation. A user password protection function also helps control access to programmed settings.

The probe is made from titanium alloy, providing a durable sonication interface. The supplied 6 mm (1/4 inch) probe is suitable for processing sample volumes of approximately 0.5–500 mL, depending on the application and sample characteristics.

Applications

The Techtom Probe Sonicator is suitable for biotechnology laboratories, pharmaceutical research, chemical laboratories, life-science research, microbiology, nanotechnology and material-science applications.

It can be used for sample homogenization, cell disruption, emulsification, dispersion and other ultrasonic laboratory processing applications. Therefore, it is useful for research laboratories that require controlled probe-based sonication.

Main Features

• Techtom Probe Sonicator
• 4.3-inch TFT touchscreen display
• Microprocessor-controlled operation
• Fully programmable operation
• 20–25 kHz operating frequency
• Automatic frequency tracking
• Automatic fault alarm
• User password protection
• Time-setting function
• Sound-proof design
• Titanium alloy probe
• 6 mm (1/4 inch) probe diameter
• Approx. 0.5–500 mL processing capacity

Technical Specifications

Specification	Details
Brand	Techtom
Product Type	Probe Sonicator
Display	4.3-Inch TFT Touchscreen
Control	Microprocessor Controlled
Programmability	Fully Programmable
Frequency	20–25 kHz
Frequency Control	Automatic Tracking
Fault Protection	Automatic Fault Alarm
User Protection	Password Protection
Processing Capacity	Approx. 0.5–500 mL
Probe Material	Titanium Alloy
Probe Diameter	6 mm (1/4")
Housing	Sound-Proof Design
Application	Ultrasonic Sample Processing
Condition	Brand New

Benefits of Techtom Probe Sonicator

The Techtom Probe Sonicator provides laboratories with a flexible solution for controlled ultrasonic sample processing. Its programmable microprocessor control allows users to adjust operating parameters according to their experimental requirements.

The 20–25 kHz frequency range and automatic frequency tracking support consistent sonication during sample processing. In addition, the titanium alloy probe provides a durable interface for transferring ultrasonic energy directly into the sample.

The touchscreen interface makes operation convenient, while password protection helps prevent unwanted changes to programmed settings. Furthermore, the sound-proof design can provide a more comfortable laboratory working environment.

Additional Information of Techtom Probe Sonicator

The Techtom Probe Sonicator is supplied as brand-new laboratory equipment with a 6 mm (1/4 inch) titanium alloy probe and sound-proof housing.

The system is suitable for processing approximately 0.5–500 mL sample volumes, depending on the sample and application. Probe selection and operating conditions should be matched to the intended laboratory process.

• National Center for Biotechnology Information
• National Library of Medicine

Brand New Condition

This is a brand-new Techtom Probe Sonicator. The instrument is supplied as new laboratory equipment with a 4.3-inch TFT touchscreen, programmable microprocessor control, sound-proof housing and 6 mm titanium alloy probe.
